5W10W20W Green Laser Light Outdoor Waterproof

Description

Specification
Diode:Janpan Nichia Laser Diode
Voltage:AC110v-240V50/60Hz
Total Power:200W
Green Diode（G）:5000MW(520NM)
Scanner Angle:60º Standard scanning unit and scanning drive circuit, the maximum
speed is 30000PPS
Life:10000hour
Divergence angle:＜1.2mrad
Control mode:Sound Control/Auto/ DMX512 Control/Master-Slave synchronization,
ILDA interface (can be connected to ISHOW software and imported pangolin pangolin, Phoenix software
DMX Control:27 channel control, black field function, PC interface, compatible with
ILDA standard computer laser show.
Software Control:All ILDA signals are converted by electronic switches Full-color animation laser, using high-speed pantograph scanning speed,patterns with broken pen, strobe, rotation,Rolling, moving, stretching, zooming, drawing, speed
SD card system:Patterns and fonts can be made through Laser Controller
DMX effects:Color, strobe, line segment plus highlights, horizontal movement,vertical movement, zoom, X flip, Y flip, center forward and reverse, gradual drawing, X wave special effect, Y wave special effect, (when selecting the analog laser, red, green and blue can be Separately modulate brightness)
Security:When the motor system fails and the laser has a single point, the laser can be automatically and quickly turned off,equipped with a safety ring
ILDA interface:Standard computer laser show software control, such as (Quickshow)
pangolin, editable font animation and other effects,adopt electronic switch conversion, automatic identification of parallel port lineLaser modulation TTL or analog can be selected, (frequency range 0~3Khz). When controlled by computer software. The visual
brightness is high in TTL state, and it is 7-color display. The visual brightness is slightly lower in the simulation state, and the laser brightness and color can be linearly controlled.
Features:Laser light source: imported laser, high stability and long service life
Laser design: Power-off protection system device, waterproof,dustproof, moisture-proof, anti-corrosion, anti-rust, and a good sealing system, efficient cooling and heat dissipation area covering 50% of the chassis area. .The built-in temperature control system can automatically adjust the temperature and work stably at -40°-45°.Built-in American pangolin FB4 professional laser light control software, which can play the programmed beam/animation laser program offline.Optical platform, optical bracket, laser special lens, laser special laser lamp constant temperature device, laser special aluminum alloy chassis
