Description
Technical Parameters:
Features: The latest third-generation
Voltage：AC100V-240V,50/60HZ
Light source：OSRAM SIRIUS HRI 461
Total power：650W
Beam angle：Parallel Beam angle 2 degrees，Solid Image Outlet Hole7mm
Linear dimming: independent dimming device, 0-100% linear dimming
High-speed strobe: pulse strobe, strobe speed 1-20 times per second
Fixed color: 1 fixed color wheel, including 14 color chips + white light, half-color
effect, linear color conversion and two-way variable speed rotating rainbow effect
Static pattern: a fixed pattern wheel, containing 14 patterns
Prism: a (8+16) prism
Focusing: high-precision glass optical lens, electronic linear high-definition
adjustment
Colorful: 1 independent colorful effect
Color chip quality: Imported from Italy, special high-temperature-resistant raw
materials, to achieve strong, bright vividness.
Horizontal/vertical: horizontal
scanning angle 540 degrees (16BIT precision scanning), vertical scanning angle
270 degrees (16BIT precision scanning) XY motor: three-phase motor.
Three-phase motor drive, powerful, faster, smoother and quieter
Lens size: 152mm
Channel mode: 16 international standard DMX512 channels
Bulb function: channel switch bulb and startup light bulb function
Appearance: high temperature resistant cast aluminum shell, adopts wind direction
drainage and intelligent temperature monitoring technology
Net weight of lamp body: 24kg
Protection class: IP65
Lamp size: 40*33*64cm
Outer packgae: 49*42*65cm
